Solid/ Domestic Waste IncineratorWaste Type: Domestic WasteAverage Emissions Rates: Not to exceed EU Standard Limits (Total dust “mg/m3”: 30; Sulphur Dioxide: 200; Nitrogen Dioxide: 400; Carbon Monoxide: 100)Minimum Burn Rate: 2,000 kg per day (up to 1,500-person camp); top loadingInsulation: high-grade fireproof insulation backing.Loading/Ash removal: Manual loading and ash removal from side door or tray.External Finish: high-temperature coatControls: Fully automatic control through PLC system for burn chamber temperature; burn and cool down cyclesOperational Temperature: 850-13300CBurner/s: Fully automatic, high-efficiency burners with electronic ignition, flame recognition sensors with combustion control features; Burner Fuel: Diesel; Electrical supply: Single, 220-240V; or 3-phase, 380-415V, 50-60HzComplete kit with chimney, filters (if applicable) and 2 years spare parts.Manufacturer specification and technical datasheet shall be provided.all be provided. The primary combustion chamber is the main structure of the incinerator, fabricated from mild steel plate and stiffened with rolled steel sections. It is carried from the floor level on a substantial steel support frame. Internally the shell is lined with calcium silicate insulation and a hot face combination of super duty brickwork or high strength castable.The primary combustion chamber must ensure minimum exit temperature is not less than 850°C.One Manual Load Incinerator comprising:Manual Loading doorHorizontal solid hearth, refractory lined primary combustion chamber. Approximate dimensions 800 mm diameters x 2100mm longFull sized bulk load/ash removal door1 off diesel-fired ignition burner ― temperature controlled1 off combustion air supply fan and distribution system, automatic controlHigh capacity secondary combustion chamber with residence time not less than 2 seconds @ >850°C1 off diesel-fired afterburner ― temperature controlledControl panel ― automatic operationTemperature indication primary and secondary chambers 0-1200°C Refractory lined flanged chimney to a height of 10M above ground levelFully packaged oil type, complete with electric ignition and flame failure controls wired with continuous running fan and complete with all valves, fan and motor.Maximum rating: at least 450kW/hourBurner: arranged for on/off operationMaximum consumption: at least 9 litres/hour Average consumption: at least 4.5 litres/hour WWW.HICLOVER.COM｜Waste Incinerators ｜Auto Roll Air Filters Nanjing Clover Medical Technology Co.,Ltd. Tel: +86-25-8461 0201 Mobile: +86-13813931455(whatsapp/wechat)Website: www.hiclover.com Email: sales@hiclover.comEmail: hicloversales@gmail.com Items/Model TS10(PLC) TS20(PLC) TS30(PLC) TS50(PLC) TS100(PLC) Burn Rate (Average) 10 kg/hour 20 kg/hour 30 kg/hour 50 kg/hour 100 kg/hour Feed Capacity(Average) 20kg 40kg 60kg 100kg 200 kg Control Mode PLC […]
